properties

• Universal tri-band UMTS/HSDPA 850/1900/2100 MHz

• Bring 10/100Base-T and serial devices together

• Choice of operation modes, including TCP Server, TCP Client, UDP, Real COM, Reverse Real COM, and RFC2217

• Secure modes for TCP Server, TCP Client, Real COM, and Reverse Real COM

• Redundant DC power inputs

• Two digital inputs and 1 relay output

• DIN-Rail

description

The OnCell G3100-HSDPA series of high-speed industrial-grade IP gateways are intelligent and fully-featured wireless communication platforms that connect your legacy serial devices over a cellular TCP/IP network. The OnCell G3100-HSDPA series offers connectivity to all tri HSDPA/UMTS frequency bands, as well as all quad GSM/GPRS/EDGE frequency bands (850/900/1800/1900 MHz), used in Europe and the United States, allowing seamless global roaming on the best available network.
The OnCell G3100-HSDPA offers versatile operation modes such as Reverse Real COM mode for cellular network structures (to handle the IP address issue), which automatically generates a virtual COM port to match serial ports, allowing you to communicate with remote serial devices.
The OnCell G3100-HSDPA also comes with a built-in relay output that can be configured to indicate the priority of events when notifying or warning engineers in the field. Two digital inputs also allow you to connect basic I/O devices, and the OnCell G3100-HSDPA comes with redundant power inputs to assure non-stop operation.

further informations

Ordering Information
Available Models
On Cell G3110-HSDPA:	1-port RS-232 to UMTS/HSDPA IP gateway
On Cell G3150-HSDPA:	1-port RS-232/422/485 to UMTS/HSDPA IP gateway
Optional Accessories (can be purchased separately)
DC Power Supply (screw-on):	See Appendix A
Power Jack to Terminal Block Cable:	See Appendix A
ANT-WCDMA-ASM-1.5:	Omni 1.5dBi/10cm, magnetic SMA tri-band antenna (impedance = 50 ohms)
ANT-WCDMA-AHSM-04-2.5m:	Omni 4dBi/11cm, magnetic SMA tri-band antenna, 2.5 m (impedance = 50 ohms)
